MPEG2 Transport Stream Analyzer

+
  • 码流分析仪BTA-P200(透明背景).gif

MPEG2 Transport Stream Analyzer

4-in-1:TS Playing, Recording, Decoding and Analyzing;   Real-time TR101290 Monitoring, Triggerrecording;   ASI I/O; RF Input(DVB-C/-T/-S/S2,DTMB) .

Classification：

Test instrument

appendix：

System Introduction

BTA-P200

  •       4-in-1: TS Playing, Recording, Decoding and Analyzing;
  •       Real-time TR 101 290 Monitoring, Trigger recording;
  •       ASI I/O; RF Input (DVB-C/-T/-S/S2,DTMB)


FEATURES:

Real-time / file analysis, playing out, monitoring and recording of MPEG2 transport streams;

Compact size, multiple analysis modules;

User-definable TR 101 290 conformance monitoring (Priority 1,2 &3) ;

Support TSoverIP analyzing ( PC Network interface requested);

Support Trigging and scheduled TS recording;

Support MPEG2/MPEG4 AVC/H.264 SD,HD decoding;

TS recording is synchronously with TS decoding;

Full log survey including measurement log and error log;

ASI Input/Output; RF Input (DVB-C/T/S2,DTMB);

ASI Input bit rate：Maximum 120Mb/s;

APPLICATIONS:

Monitor & debug MPEG-2/DVB encoder and multiplexer

Monitor digital satellite, terrestrial, and cable systems

Monitor and debug digital video broadcasting system
